+603-3323 5186Bosch GPL 5 Professional
Five precise points, quickly aligned
Self-levelling horizontal and vertical pendulum point laser for indoor and outdoor work
High visibility of the laser points with a working range of 30 m
Extremely precise in use with an accuracy of ±3 mm at a distance of 10 m
Scope of delivery: GPL 5 Professional
| Part no. | 0 601 066 200 |
|---|---|
| Protective bag |
 |
| Wall mount |
|
| 3 x 1.5 V batteries |
|
Features: GPL 5 Professional
- Horizontal, and cross-line mode
- Light weight and highly compact size
- Multifunctional wall mount
Technical data: GPL 5 Professional
| Laser diode | 635 nm, < 1 mW |
| Laser class | 2 |
| Working range | 30 m |
| Levelling accuracy | ± 0,3 mm/m |
| Self-levelling range | ±4° |
| Dust and splash protection | IP 5X |
| Power supply | 3 x 1.5V LR6 (AA) |
| Operating duration, max. | 24 h |
| Tripod connection | 1/4" & 5/8" |
| Weight | 0.25 kg |
| Length | 104 mm |
| Width | 40 mm |
| Height | 80 mm |
